ELEOPTION® 7 “LCD monitor TFT LCD Digital Peephole Viewer Door Eye Video Audio Color Camera (7.0 Inch)

Basic specification for 7″ TFT LCD Transmission frequency: ISM 2.400MHz ~ 2.485MHz Modulation Mode: FM Antenna Type: Camera Omni; Receiver; Directional transmission distance: Min. 100m transmission distance without blocks Antenna Port: 50ohm SMA Receiving Sensitivity: ≤-85dBm Vided output level: 1Vp-p@75ohm Audio Output level: 1Vp-p@600ohm Operating Temperature: -10℃ ~ +50℃ / +14 ~ +122F Storage Temperature:

Basic specification for 7″ TFT LCD

Transmission frequency: ISM 2.400MHz ~ 2.485MHz Modulation Mode: FM
Antenna Type: Camera Omni; Receiver; Directional transmission distance: Min. 100m transmission distance without blocks
Antenna Port: 50ohm SMA
Receiving Sensitivity: ≤-85dBm
Vided output level: 1Vp-p@75ohm
Audio Output level: 1Vp-p@600ohm
Operating Temperature: -10℃ ~ +50℃ / +14 ~ +122F
Storage Temperature: -20℃ ~ +60℃ / -4 ~ +140F
Operating Humidity: 85%RH
Screen Size: 7.0 inch
Power Supply: DC12V 1.5A
Dimensions (W*D*H): 190*140*20mm
Weight: 425g

Technical specification for wireless camera

Model: 802C
Image Sensor: 1/3″ OmniVision CMOS
TV System: PAL/NTSC
Validity Pixel: PAL: 628×582, NTSC: 510×492
Horizontal Definition: 380Line
Scan Frequency: PAL/CCIR: 50Hz, NTSC/EIA: 60Hz
Angular Field of View: 45° (f=6mm)
Minimum Illumination: 0Lux
Input Power: 27dBm
Output Frequency: 2.4GHz (2.414GHz、2.432GHz、2.450GHz、2.468GHz)
Frequency Control: Adapt to MPU and phase locked loop to control frequency exactly, which possesses high stability.
Transmitting Signal: Ideo & Audio
Open transmission: Distance 100M
Infrared Distance: 10~15M
Power: DC12V/500mA
Current: 350mA
Power Consumption: ≤4W
Working Temperature: -10~+50℃
Size: 68×52×105 mm
Weight: 230g Lieferumfang: 2 x Mini wireless cameras 2 x Camera power EU adapters 1 x 7.0″ LCD Monitor 1 x Monitor Adapter 1 x A/V line 1 x Remote Control 1 x Englisch Manual

Product Features

  • 7 “LCD monitor with built-in video recorder, 380TV lines clear picture, Built-in microphone for audio monitoring
  • Super 380TV lines clear picture display ,Built-in IR lights for night vision range and microphone for audio monitoring
  • Minimum 100m transmission range without hindrance
  • Waterproof camera suitable for outdoor use. Video output function for larger screen.
  • Digital, wireless 4-channel camera and video recording system. Easy installation. No wiring required. Completely digital wireless network, interference-free and without gaps.
